OUR PRODUCTION PROCESS
With Grade, Hardness and chemical Composition.
With heating, dyes and hammers by our skilled craftsman after forging every instrument inspected.
Cutting, shaping and bending. Shaping the working points, Drilling holes, screw
Grinding with grind wheel for reducing excessive amount metal and finning the shape (Extra Coarse). Filing with metal fills stick, exact sizing and shape, fining the working points.
In inspection we do comparing with master sample or International catalog and expelling faulted instruments. in testing group of 12 pieces With required spacing entered in temper machine and chemicals then hardness test machine we test the temper.
Annealing process maintain the hardness for less brokerage. in grinding every instruments inside and outside grinded with sand papers grits belts on wheels (Medium Coarse (100) Fine Coarse, (120) and very fine Coarse (180, 220).
Joining the instruments and screwing, sharping etc.
Dipped in chemical with electric current.
By Skilled person check the working points, sharpness and adjusting.
After Extra Coarse, Medium Coarse for final finishing every instrument grinded with (Super Fine 320
and ultra fine 400/600) before polish or dull.
Polish or Dull with wheel and chemical bar, meanwhile some instruments are especially Polish
in vibrator machines.
Passivation with chemicals.
Pre-Clean 105 —————-> Citrisurf 2250 (USA) & Passivate 606 —————-> Neutralyer N5 —————-> Boiling Test
30-min – 70-80C 45-min – 70-80C 30-min – 70-80C 30-min > 100C
Most of the instruments are sanded inside like Forceps, pliers etc.
After sand rest part will be refinished and buffed. Instruments involving screw are lubricated. Lubricating the instruments moveable portions and final inspection like checking for operation, measurement, polish and usability.
With special care to avoid the engraving skilled person did this job laser stamping / maring machine. Every instrument cleaned one by one and packed in small box with 100 / 50 / 25 PCS quantity per box & then packed into big hard box as per requirement
